As an open source no-code/low-code platform to visually build enterprise web apps for coders and non-coders, Joget is an ideal complement to OpenShift to fill the gap. The Joget platform is now available as a Red Hat Certified Container, so it is trusted, secure and commercially supported on OpenShift. This article describes the steps in deploying the certified Joget container image running with the MySQL database.
If you do not have an account, you can acquire one by registering for one of the following options:
Under the selected project, select Add to Project > Deploy Image and click on the create an image pull secret link. In the ensuing popup, key in the Red Hat login details for the registry.
|
Secret Name
|
registry.connect.redhat.com
|
|
Authentication Type
|
Image Registry Credentials
|
|
Image Registry Server Address
|
registry.connect.redhat.com
|
|
Username
|
Red Hat account username
|
|
Password
|
Red Hat account password
|
|
Email
|
Red Hat account email
|
|
Link secret to a service account
|
Yes
|
|
Service Account
|
default
|
Once the secret has been created, select Add to Project > Deploy Image, select the Image Name option and key in registry.connect.redhat.com/joget/joget-v6-enterprise. Click on the small search icon to load the image details from the registry, key in the desired Name then click Deploy.
|
Image Name
|
registry.connect.redhat.com/joget/joget-v6-enterprise
|
|
Name
|
joget-v6-enterprise
|
Step 4: Add Persistent Storage
The next step is to add persistent storage to the container for storing configuration files and persistent file uploads. Under Applications > Deployments, select the application, then the Configuration tab. Scroll down to the Volumes section and click on the Add Storage link.
In the Add storage page, click on the small create storage link. Create the new storage with the desired values e.g.
|
Name
|
joget-data
|
|
Access Mode
|
Shared Access (RWX)
|
|
Size
|
1GB (or as required)
|
Back in the Add Storage page, select the newly created storage, set the Mount Path to /opt/joget/wflow, then Add.
|
Mount Path
|
/opt/joget/wflow
|
Step 5: Create Service Route for External Access
At this point, the service is not accessible from an external web browser so you will need to create a route, which exposes a service at a host name.
Click on Applications > Services and select joget-v6-enterprise.
Select Actions > Create Route, set the Path to /jw and click on Create.
Return to the Overview and click on the URL next to the application name to launch the Joget platform.
Deploy Joget using the OpenShift CLI
For those more inclined to use a non-graphical command line interface, it is actually faster to use the OpenShift command line interface (CLI) to deploy the Joget platform.
The following is a Linux script to accomplish a similar Joget platform deployment. Before running this script, install the CLI and login. Change the environment variables in the script accordingly, at least the four values below:
|
PROJECT_NAME
|
The desired project name
|
|
REGISTRY_USERNAME
|
Red Hat account username
|
|
REGISTRY_PASSWORD
|
Red Hat account password
|
|
REGISTRY_EMAIL
|
Red Hat account email
|
#!/bin/sh
export PROJECT_NAME=joget-openshift
export REGISTRY_USERNAME=email@domain
export REGISTRY_PASSWORD=password
export REGISTRY_EMAIL=email@domain
export REGISTRY_SERVER=registry.connect.redhat.com
export IMAGE_NAMESPACE=joget
export IMAGE_NAME=joget-v6-enterprise
export IMAGE_TAG=latest
export APP_NAME=joget-v6-enterprise
export DB_APP_NAME=joget-mysql
export STORAGE_NAME=joget-data
export MYSQL_DATABASE=jwdb
export MYSQL_USER=joget
export MYSQL_PASSWORD=joget
echo === deploy Joget on OpenShift ===
echo PROJECT_NAME: $PROJECT_NAME
echo REGISTRY_SERVER: $REGISTRY_SERVER
echo REGISTRY_USERNAME: $REGISTRY_USERNAME
echo REGISTRY_EMAIL: $REGISTRY_EMAIL
echo IMAGE_NAMESPACE: $IMAGE_NAMESPACE
echo IMAGE_NAME: $IMAGE_NAME
echo IMAGE_TAG $IMAGE_TAG
echo IMAGE_NAME: $IMAGE_NAME
echo APP_NAME: $APP_NAME
echo DB_APP_NAME: $DB_APP_NAME
echo STORAGE_NAME: $STORAGE_NAME
echo MYSQL_DATABASE: $MYSQL_DATABASE
echo MYSQL_USER: $MYSQL_USER
echo MYSQL_PASSWORD: $MYSQL_PASSWORD
echo === create project ===
oc new-project $PROJECT_NAME
echo === deploy MySQL ===
oc new-app openshift/mysql:5.7 –name $DB_APP_NAME -e MYSQL_USER=$MYSQL_USER -e MYSQL_PASSWORD=$MYSQL_PASSWORD -e MYSQL_DATABASE=$MYSQL_DATABASE
echo === create and bind secret to pull Joget image ===
oc create secret docker-registry $REGISTRY_SERVER –docker-server=$REGISTRY_SERVER –docker-username=$REGISTRY_USERNAME docker-password=$REGISTRY_PASSWORD –docker-email=$REGISTRY_EMAIL
oc secrets link default $REGISTRY_SERVER –for=pull
echo === import Joget image ===
oc import-image $PROJECT_NAME/$IMAGE_NAME –from=$REGISTRY_SERVER/$IMAGE_NAMESPACE/$IMAGE_NAME –confirm
#echo === grant pull permission if from different project ===
#oc policy add-role-to-user system:image-puller system:serviceaccount:$PROJECT_NAME:default -n $IMAGE_NAMESPACE
echo === deploy Joget ===
oc new-app $PROJECT_NAME/$IMAGE_NAME:$IMAGE_TAG -e GC_MAX_METASPACE_SIZE=300 –name $APP_NAME
echo === create persistent storage claim ===
cat <<EOF > pvc.yaml
apiVersion: “v1”
kind: “PersistentVolumeClaim”
metadata:
name: “$STORAGE_NAME”
spec:
accessModes:
– “ReadWriteMany”
resources:
requests:
storage: “1Gi”
EOF
oc create -f pvc.yaml
rm pvc.yaml
echo === mount storage ===
oc set volume dc/$APP_NAME –add –type=persistentVolumeClaim –claim-name=$STORAGE_NAME –mount-path=/opt/joget/wflow
echo === expose service route for external excess ===
oc expose svc $APP_NAME –path=/jw
oc annotate route $APP_NAME –overwrite haproxy.router.openshift.io/timeout=60s
oc get route
echo URL:
http://$(oc get route $APP_NAME –template='{{ .spec.host }}’)/jw
Setup Database
The first time the Joget platform is accessed, the Database Setup page will be displayed. Configure the database settings using the values defined when deploying the MySQL database previously e.g.
|
Database Host
|
jogetdb
|
|
Database Port
|
3306
|
|
Database Name
|
jwdb
|
|
Database User
|
joget
|
|
Database Password
|
joget
|
Upon successful configuration, the Joget
App Center will be loaded.
